ERMIS 550B

The Raijintek ERMIS series – A SFX Design piece for your Mini ITX Systems. Available in 450W and 550W Watts, with features such as the PSU Flat Cabling & 80+ Bronze @ 230V EU levels of efficiency - 85% at 50%, 82% at 20%/100%. Each unit meets ErP Lot 2013, with < 0.5W consumed on standby. Each ERMIS SFX power supply uses high ampere multi +12V Rails to provide the most stable amount of power when needed. The supplied 80mm fan is profiled for quiet operation at all loads.

Product Name	ERMIS 550B
Product Number	0R30B00002
Type	SFX
Max. Output Capacity	550W
Dimension [W×H×D]	125×100×64 mm
Color	Black
Input Current	8-4A
Input Frequency Range	47-63Hz
Input Voltage	100-240V
Operating Temperature	0°C to +40°C
Operating Humidity	20% to 90%, non-condensing
Storage Temperature	-20 °C to +70 °C
Storage Humidity	5% to 95%, non-condensing
Cooling System	80mm Fan: 3000 R.P.M. ± 10%
Efficiency	Meet 80 PLUS® Bronze
MTBF	100,000 hrs minimum
Protection	Over power protection, Over voltage protection, Short circuit protection
PCI-E 6+2pin	2
Safety Approval	cTUVus / TUV / CE / FCC / CB
