Fully modular design
High quality 100% Japanese capacitors
140mm smart control fan
80 Plus Platinum certified
Single +12V rail
Supports NVIDIA SLI / AMD CROSSFIRE

SPECIFICATIONS
Model: XP1200M
Type: Intel Form Factor ATX 12V v2.31
PFC: Active PFC (>0.9 typical)
Input Voltage: 115-240 Vac (full range)
Input Current: 10A
Input Frequency: 60-50 Hz
Output Capacity: 1200W
Dimension: D180 x W150 x H86mm
Fan Type: 140mm Double ball bearing fan
80 PLUS: Platinum
Efficiency: 92% at typical load
MTBF: >100,000 hours
Protection: OVP/OPP/SCP/UVP/OCP/OTP
Cable Type: Black Flat Cables
Regulatory: CE/BSMI/EAC/TUV/FCC/CCC/RCM
Connectors:
ATX/MB 20+4 Pin x 1 : 700mm*1
CPU/EPS 4+4 Pin x 2 : 800mm*1+ 650mm*1
PCI-e 6+2 Pin x 6 : 650mm*2 + (650mm+100mm)*2
SATA x 12 : (550mm+150mm+150mm+150mm)*3
4 Pin Peripheral x 8 : (550mm+150mm+150mm+150mm)*2
4 Pin Floppy x 2 : 100mm*2
